CMA CGM BOUGAINVILLE
9702156 | 9HA5334 | CMA by *********************** Last update: Wed Feb 05 2025

General Info

Ship Name:CMA CGM BOUGAINVILLE
IMO Code:9702156
Call Sign:9HA5334
Line Operator:CMA
Class Name for Sister Ships:CGBO
Year Built:2015
Position Format:Bay, Row, Tier
Allowed Containers:20, 40, 45
LPP (LBP):0.00
LOA (Length Overall):0.00
Stern to AFT PP:-
Features Informed:Standard
Also Known As...:-

Size Summary

ISO Bays:093
Max ISO Row:20
Center Line Row:Yes
Max Above ISO Tier:92
Min Above ISO Tier:66
Max Below ISO Tier:22
Min Below ISO Tier:02
Total TEU:17,726

Centers of Gravity

LCG Values:Known
LCG Data:100%
VCG Values:Estimated
VCG Data:0%
TCG Values:Known
TCG Data:100%
