MSC HONG KONG V
9231810 | 5LCO9 | MSC by ************************** Last update: Fri Jun 23 2023

General Info

Ship Name:MSC HONG KONG V
IMO Code:9231810
Call Sign:5LCO9
Line Operator:MSC
Class Name for Sister Ships:MHK
Year Built:2002
Position Format:Bay, Row, Tier
Allowed Containers:20, 40, 45
LPP (LBP):283.20
LOA (Length Overall):294.10
Stern to AFT PP:-
Features Informed:
Also Known As (old names):-

Size Summary

ISO Bays:069
Max ISO Row:12
Center Line Row:Yes
Max Above ISO Tier:94
Min Above ISO Tier:82
Max Below ISO Tier:16
Min Below ISO Tier:02
Total TEU:4,992

Centers of Gravity

LCG Values:Known
LCG Data:100%
VCG Values:Known
VCG Data:100%
TCG Values:Known
TCG Data:100%

Side View

Side view of MSC HONG KONG V

Hatch-Covers View

Deck view of MSC HONG KONG V

ISO Bays

Legend
  • 20'
  • 40'
  • 45'
  • Reefer
  • Restricted slot

001 (002)

Bay 001 view and slots of MSC HONG KONG V

003

Bay 003 view and slots of MSC HONG KONG V

005 (006)

Bay 005 view and slots of MSC HONG KONG V

007

Bay 007 view and slots of MSC HONG KONG V

009 (010)

Bay 009 view and slots of MSC HONG KONG V

011

Bay 011 view and slots of MSC HONG KONG V

013 (014)

Bay 013 view and slots of MSC HONG KONG V

015

Bay 015 view and slots of MSC HONG KONG V

017 (018)

Bay 017 view and slots of MSC HONG KONG V

019

Bay 019 view and slots of MSC HONG KONG V

021 (022)

Bay 021 view and slots of MSC HONG KONG V

023

Bay 023 view and slots of MSC HONG KONG V

025 (026)

Bay 025 view and slots of MSC HONG KONG V

027

Bay 027 view and slots of MSC HONG KONG V

029 (030)

Bay 029 view and slots of MSC HONG KONG V

031

Bay 031 view and slots of MSC HONG KONG V

033 (034)

Bay 033 view and slots of MSC HONG KONG V

035

Bay 035 view and slots of MSC HONG KONG V

037 (038)

Bay 037 view and slots of MSC HONG KONG V

039

Bay 039 view and slots of MSC HONG KONG V

041 (042)

Bay 041 view and slots of MSC HONG KONG V

043

Bay 043 view and slots of MSC HONG KONG V

045 (046)

Bay 045 view and slots of MSC HONG KONG V

047

Bay 047 view and slots of MSC HONG KONG V

049 (050)

Bay 049 view and slots of MSC HONG KONG V

051

Bay 051 view and slots of MSC HONG KONG V

053 (054)

Bay 053 view and slots of MSC HONG KONG V

055

Bay 055 view and slots of MSC HONG KONG V

057 (058)

Bay 057 view and slots of MSC HONG KONG V

059

Bay 059 view and slots of MSC HONG KONG V

061 (062)

Bay 061 view and slots of MSC HONG KONG V

063

Bay 063 view and slots of MSC HONG KONG V

065 (066)

Bay 065 view and slots of MSC HONG KONG V

067

Bay 067 view and slots of MSC HONG KONG V

069 (070)

Bay 069 view and slots of MSC HONG KONG V
